How to Install and Configure Istio Ingress with Helm

Introduction

This article offers an overview of the Helm install process and the IngressController implementations for Istio. Upon completing this tutorial, you should be able to deploy a complete, working Istio IngressController via Helm as per the Istio getting started documentation. Note: This article assumes Istio 1.20.1. See also Istio issue 46791 ›

Install Istio

The following changes the default installation documentation here. The documented process installs the Istio Gateway into a different location than is expected by the configuration.

Add the Istio helm repository:

helm repo add istio https://istio-release.storage.googleapis.com/charts

Create the namespace and install the base chart:

kubectl create ns istio-system
helm install istio-base istio/base -n istio-system

Install and configure istiod:

helm upgrade --install istiod istio/istiod -n istio-system \
  --set meshConfig.ingressSelector=istio-ingress \
  --set meshConfig.ingressService=istio-ingress \
  --set pilot.env.K8S_INGRESS_NS=istio-ingress

Note: The public documentation installs the gateway into a location that is not expected. Here we change those defaults to accommodate this. See the following:

• Mesh config
• pilot-discovery env vars

Install the gateway as per the documentation:

kubectl create ns istio-ingress
helm install istio-ingress istio/gateway -n istio-ingress

Note:If the istiod installation has not been customized, the gateway should be installed as per below:

helm install istio-ingressgateway istio/gateway -n istio-system

IngressClass

The following defines the Istio IngressClass:

cat <<EOF | kubectl apply -f -
apiVersion: networking.k8s.io/v1
kind: IngressClass
metadata:
  name: istio
  annotations:
    ingressclass.kubernetes.io/is-default-class: "true"
spec:
  controller: istio.io/ingress-controller
EOF

httpbin

The following installs the httpbin application:

kubectl apply -f https://raw.githubusercontent.com/istio/istio/master/samples/httpbin/httpbin.yaml

And create the Ingress resource:

cat <<EOF | kubectl apply -f -
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: httpbin
spec:
  ingressClassName: istio
  rules:
  - host: httpbin.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: httpbin
            port:
              number: 8000
EOF

Validation

Check to see that the Helm values are correct:

$ helm get values istiod -n istio-system
USER-SUPPLIED VALUES:
meshConfig:
  ingressSelector: istio-ingress
  ingressService: istio-ingress
pilot:
  env:
    K8S_INGRESS_NS: istio-ingress

The Ingress resource should have an external IP address associated with it:

$ kubectl get ingress -A
NAMESPACE   NAME      CLASS   HOSTS                 ADDRESS        PORTS   AGE
default     httpbin   istio   httpbin.example.com   192.168.0.21   80      7s

Note: If there is no external IP, the field is blank, then the Ingress resource has not been implemented upon a gateway.

Conclusion

As you can see from the above, the default Istio installation relies upon several distinct, default configuration values which are correct when deploying with the supplied istioctl profiles. When Helm is used to deploy, specific configuration away from those defaults is much easier. You should now have enough information to be able to find and alter those default values.
