Introduction
In this article, we’ll explore how to use Hashicorp Vault as a more secure way to store Istio certificates than using Kubernetes Secrets. By default, Secrets are stored in etcd using base64 encoding. In environments with stringent security policies, this might not be acceptable, so additional security measures are needed to protect them. One such solution involves storing secrets in an external secret store provider, like HashiCorp Vault.
Tetrate offers an enterprise-ready, 100% upstream distribution of Istio, Tetrate Istio Subscription (TIS). TIS is the easiest way to get started with Istio for production use cases. TIS+, a hosted Day 2 operations solution for Istio, adds a global service registry, unified Istio metrics dashboard, and self-service troubleshooting.
Get access now ›
Vault can be hosted both inside and outside a Kubernetes cluster. In this case, we will explore using Vault hosted outside kubernetes, so that it can provision secrets for multiple clusters at once. The setup is also ideal for exploring Istio’s multi-cluster feature, which requires a shared trust domain.
Leveraging the vault-agent-init container, we can inject certificates and private key material into the actual Istio control plane Pods so they are bootstrapped with the external CA certificates. This avoids the dependency on Secrets to bootstrap the Istio control plane. Exactly the same technique can be used for ingress and egress certificates.
More information on how certificates are used and managed within Istio, can be found in the official documentation:
- Identity and certificate management
- Plug in CA Certificates
- Custom CA Integration using Kubernetes CSR
For best practices based on real-life production experience, also check out the following Tetrate blog posts:
- Trusting trust: Root Istio’s trust in your existing PKI
- Automate Istio CA rotation in production at scale
The code accompanying this blog post can be found at the following repository:
https://github.com/tetratelabs/istio-vault-ext-certs
Istiod Certificate Handling
Although some of the decision logic is explained in the forementioned blogposts, it is worthwhile to also refer to the source code to find some undocumented behavior.
// istio/pilot/pkg/bootstrap/istio_ca.go
//
// For backward compat, will preserve support for the "cacerts" Secret used for self-signed certificates.
// It is mounted in the same location, and if found will be used - creating the secret is sufficient, no need for
// extra options.
//
// In old installer, the LocalCertDir is hardcoded to /etc/cacerts and mounted from "cacerts" secret.
//
// Support for signing other root CA has been removed - too dangerous, no clear use case.
//
// Default config, for backward compat with Citadel:
// - if "cacerts" secret exists in istio-system, will be mounted. It may contain an optional "root-cert.pem",
// with additional roots and optional {ca-key, ca-cert, cert-chain}.pem user-provided root CA.
// - if user-provided root CA is not found, the Secret "istio-ca-secret" is used, with ca-cert.pem and ca-key.pem files.
// - if neither is found, istio-ca-secret will be created.
// - a config map "istio-security" with a "caTLSRootCert" file will be used for root cert, and created if needed.
// The config map was used by node agent - no longer possible to use in sds-agent, but we still save it for
// backward compat. Will be removed with the node-agent. sds-agent is calling NewCitadelClient directly, using
// K8S root.
In order to instruct Istio to pick up our certificates elsewhere compared to the standard kubernetes secrets, we will leverage an environment variable (documented here) for istio-pilot (aka istiod or the Istio control plane), so certificates will be picked up from an alternative location within the Kubernetes Pod. This is needed because the vault-agent-init injection container will create a new mounted volume /vault/secrets
to drop the certificates and private key we instrument it to pull from the external vault server.
Variable Name | Type | Default Value | Description |
ROOT_CA_DIR | String | /etc/cacerts | Location of a local or mounted CA root |
Pod Annotations for the vault-agent-init Container
We will be leveraging Vault injector annotations to instruct the sidecar what data to pull and what Vault role to use when doing so. We also make sure the vault-agent-init
container is run before our actual istiod
main containers, so the latter can pick up the certificates and key material to bootstrap itself correctly. Vault annotations are enumerated and documented here. The relevant annotations we will be using in this tutorial are as follows:
Annotation | Default Value | Description |
vault.hashicorp.com/agent-inject | “false” | Configures whether injection is explicitly enabled or disabled for a Pod. This should be set to a true or false value. |
vault.hashicorp.com/agent-init-first | “false” | Configures the Pod to run the Vault Agent init container first if true (last if false). This is useful when other init containers need pre-populated secrets. This should be set to a true or false value. |
vault.hashicorp.com/role | – | Configures the Vault role used by the Vault Agent auto-auth method. Required when vault.hashicorp.com/agent-configmap is not set. |
vault.hashicorp.com/auth-path | – | Configures the authentication path for the Kubernetes auth method. Defaults to auth/kubernetes . |
vault.hashicorp.com/agent-inject-secret- | – | Configures Vault Agent to retrieve the secrets from Vault required by the container. The name of the secret is any unique string after vault.hashicorp.com/agent-inject-secret- , such as vault.hashicorp.com/agent-inject-secret-foobar . The value is the path in Vault where the secret is located. |
vault.hashicorp.com/agent-inject-template- | – | Configures the template Vault Agent should use for rendering a secret. The name of the template is any unique string after vault.hashicorp.com/agent-inject-template- , such as vault.hashicorp.com/agent-inject-template-foobar . This should map to the same unique value provided in vault.hashicorp.com/agent-inject-secret- . If not provided, a default generic template is used. |
Vault Server Considerations
Vault supports several methods for clients to authenticate themselves. We will be leveraging the Kubernetes auth backend, which means we will be leveraging Kubernetes ServiceAccount JWT token validation. Please note that ServiceAccount tokens are no longer automatically generated since Kubernetes 1.24. You can still create those API tokens manually, as documented here.
As to storage of our certificate and private key material we have two options:
Because the PKI secret engine does not provide clean-cut APIs to retrieve the certificates and the private key we need, and because the PKI secret engine will generate a new intermediate certificate for every call (e.g., every istiod restart), we will be using the generic KV secret engine instead, storing all the values we need in a simple key-value data structure. We will assume the renewal of intermediate certificates is handled out-of-band through some service portal or CI/CD process that will store the renewed intermediate certificates in the vault server as well.
Istio’s control plane Pods need the following files in order to bootstrap its build in CA correctly:
Key | Value (PEM encoded) | Details |
ca-key.pem | CA private key | Private key of the intermediate cert, used as root CA for istiod. |
ca-cert.pem | CA public certificate | Intermediate cert, used as root CA for istiod. |
root-cert.pem | CA root certificate | The root of trust of our newly generated intermediate cert. |
cert-chain.pem | Full certificate chain | Intermediate cert at the top, root cert at the bottom. |
Setup
Prerequisites in terms of installed software, if you want to follow the local set-up, include:
- kubectl to interact with the kubernetes clusters (download)
- helm to install vault injector and istio charts (download)
- vault cli tool to configure the vault server (download)
If you want a local demo environment, please follow the instructions here, which use docker-compose to spin up a vault server and two separate k3s clusters. In case you bring your own Kubernetes clusters and an externally hosted Vault instance, skip ahead to the next section.
- docker-compose to spin up a local environment (download)
In order to progress, we expect the following shell variables to be set according to your environment.
export VAULT_SERVER=
export K8S_API_SERVER_1=
export K8S_API_SERVER_2=
Vault Kubernetes Auth Backend
As mentioned in the introduction section on Vault server considerations, we will be using the Kubernetes auth backend. Since istiod will be fetching the certificates and private key material from the Vault server, let’s start off by creating the corresponding service accounts in both clusters.
kubectl --kubeconfig kubecfg1.yml create ns istio-system
kubectl --kubeconfig kubecfg2.yml create ns istio-system
kubectl --kubeconfig kubecfg1.yml apply -f istio-sa.yml
kubectl --kubeconfig kubecfg2.yml apply -f istio-sa.yml
ServiceAccount, Secret and ClusterRoleBinding as below:
# istio-sa.yaml
apiVersion: v1
kind: ServiceAccount
metadata:
name: istiod
namespace: istio-system
labels: # added for istio helm installation
app: istiod
app.kubernetes.io/managed-by: Helm
release: istio-istiod
annotations: # added for istio helm installation
meta.helm.sh/release-name: istio-istiod
meta.helm.sh/release-namespace: istio-system
---
apiVersion: v1
kind: Secret
metadata:
name: istiod
namespace: istio-system
annotations:
kubernetes.io/service-account.name: istiod
type: kubernetes.io/service-account-token
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
name: role-tokenreview-binding
roleRef:
apiGroup: rbac.authorization.k8s.io
kind: ClusterRole
name: system:auth-delegator
subjects:
- kind: ServiceAccount
name: istiod
namespace: istio-system
NOTE: We added Helm labels and annotations on the istiod ServiceAccount in order not to have conflicts with our Istio Helm deployment later on.
Once the ServiceAccount in both clusters is created, let’s store their Secret token and ca.cert values in an output folder:
mkdir -p ./output
kubectl --kubeconfig kubecfg1.yml get secret -n istio-system istiod -o go-template="{{ .data.token }}" | base64 --decode > output/istiod1.jwt
kubectl --kubeconfig kubecfg1.yml config view --raw --minify --flatten -o jsonpath="{.clusters[].cluster.certificate-authority-data}" | base64 --decode > output/k8sapi-cert1.pem
kubectl --kubeconfig kubecfg2.yml get secret -n istio-system istiod -o go-template="{{ .data.token }}" | base64 --decode > output/istiod2.jwt
kubectl --kubeconfig kubecfg2.yml config view --raw --minify --flatten -o jsonpath="{.clusters[].cluster.certificate-authority-data}" | base64 --decode > output/k8sapi-cert2.pem
More information on the detailed content of the Kubernetes API certificate and the istiod ServiceAccount JWT token can be found here, where we also describe the vault interaction process in more depth in terms of REST API calls made to authenticate and fetch secrets. These can come in handy when debugging permission denied issues.
Let’s create the necessary Vault auth configuration based on the Kubernetes CA certs and JWT tokens just retrieved:
export VAULT_ADDR=http://localhost:8200
vault login root
vault auth enable --path=kubernetes-cluster1 kubernetes
vault auth enable --path=kubernetes-cluster2 kubernetes
vault write auth/kubernetes-cluster1/config
kubernetes_host="$K8S_API_SERVER_1"
kubernetes_ca_cert=@output/k8sapi-cert1.pem
token_reviewer_jwt=`cat output/istiod1.jwt`
disable_local_ca_jwt="true"
vault write auth/kubernetes-cluster2/config
kubernetes_host="$K8S_API_SERVER_2"
kubernetes_ca_cert=@output/k8sapi-cert2.pem
token_reviewer_jwt=`cat output/istiod2.jwt`
disable_local_ca_jwt="true"
NOTE:
VAULT_ADDR
is set to localhost in case you are using the docker-compose provided environment. Set this to$VAULT_SERVER
in case you brought your own Vault server.
Istio Certificates and Private Key in Vault kv Secrets
Next we will create a new self-signed root certificate and generate intermediate certificates for both our clusters. We will be using the helper Makefile scripts provided by upstream Istio here.
cd certs
make -f ../certs-gen/Makefile.selfsigned.mk root-ca
make -f ../certs-gen/Makefile.selfsigned.mk istiod-cluster1-cacerts
make -f ../certs-gen/Makefile.selfsigned.mk istiod-cluster2-cacerts
cd ..
More details on the actual content and the X509v3 extensions being set, can be found here. You can fine-tune the certificate generation, by the Makefile documentation here and corresponding Makefile override values.
Let’s add the generated certificates and private key into Vault kv secrets:
export VAULT_ADDR=http://localhost:8200
vault login root
vault secrets enable -path=kubernetes-cluster1-secrets kv
vault secrets enable -path=kubernetes-cluster2-secrets kv
vault kv put kubernetes-cluster1-secrets/istiod-service/certs
ca_key=@certs/istiod-cluster1/ca-key.pem
ca_cert=@certs/istiod-cluster1/ca-cert.pem
cert_chain=@certs/istiod-cluster1/cert-chain.pem
root_cert=@certs/istiod-cluster1/root-cert.pem
vault kv put kubernetes-cluster2-secrets/istiod-service/certs
ca_key=@certs/istiod-cluster2/ca-key.pem
ca_cert=@certs/istiod-cluster2/ca-cert.pem
cert_chain=@certs/istiod-cluster2/cert-chain.pem
root_cert=@certs/istiod-cluster2/root-cert.pem
Move on by restricting access to those certificates and private key per cluster, bound to the Kubernetes istiod ServiceAccount based auth backend:
echo 'path "kubernetes-cluster1-secrets/istiod-service/certs" {
capabilities = ["read"]
}' | vault policy write istiod-certs-cluster1 -
echo 'path "kubernetes-cluster2-secrets/istiod-service/certs" {
capabilities = ["read"]
}' | vault policy write istiod-certs-cluster2 -
vault write auth/kubernetes-cluster1/role/istiod
bound_service_account_names=istiod
bound_service_account_namespaces=istio-system
policies=istiod-certs-cluster1
ttl=24h
vault write auth/kubernetes-cluster2/role/istiod
bound_service_account_names=istiod
bound_service_account_namespaces=istio-system
policies=istiod-certs-cluster2
ttl=24h
Deploy vault-inject and Istio Helm Charts
In order to deploy the Vault injector, we will be leveraging the official Vault Helm charts.
helm repo add hashicorp https://helm.releases.hashicorp.com
helm repo update
kubectl --kubeconfig kubecfg1.yml create ns vault
kubectl --kubeconfig kubecfg2.yml create ns vault
helm --kubeconfig kubecfg1.yml install -n vault vault-inject hashicorp/vault --set "injector.externalVaultAddr=$VAULT_SERVER"
helm --kubeconfig kubecfg2.yml install -n vault vault-inject hashicorp/vault --set "injector.externalVaultAddr=$VAULT_SERVER"
kubectl --kubeconfig kubecfg1.yml -n vault get pods
kubectl --kubeconfig kubecfg2.yml -n vault get pods
NAME READY STATUS RESTARTS AGE
vault-inject-agent-injector-5776975795-9vt9w 1/1 Running 0 92s
NAME READY STATUS RESTARTS AGE
vault-inject-agent-injector-5776975795-9vjnx 1/1 Running 0 91s
To install Istio, we will be using the Tetrate Istio Distro Helm charts.
helm repo add tetratelabs https://tetratelabs.github.io/helm-charts
helm repo update
helm --kubeconfig kubecfg1.yml install -n istio-system istio-base tetratelabs/base
helm --kubeconfig kubecfg2.yml install -n istio-system istio-base tetratelabs/base
helm --kubeconfig kubecfg1.yml install -n istio-system istio-istiod tetratelabs/istiod --values=./cluster1-values.yaml
helm --kubeconfig kubecfg2.yml install -n istio-system istio-istiod tetratelabs/istiod --values=./cluster2-values.yaml
kubectl --kubeconfig kubecfg1.yml -n istio-system get pods
kubectl --kubeconfig kubecfg2.yml -n istio-system get pods
Note how we leverage several Istio Helm chart value overrides to accomplish our desired goal:
- Inject a pilot Pod environment variable
ROOT_CA_DIR
to tell istiod where to fetch certificates and private key - Tell the vault-agent-init container to run before the istiod container, so the secrets are available within the
/vault/secrets
mounted volume - Instruct the Vault injector to fetch secrets based on the correct location and data keys
- Assume the Vault istiod role while doing so
- Override the default Kubernetes auth-path, because we have multiple clusters
pilot:
env:
ROOT_CA_DIR: /vault/secrets
podAnnotations:
vault.hashicorp.com/agent-inject: "true"
vault.hashicorp.com/agent-init-first: "true"
vault.hashicorp.com/agent-inject-secret-ca-key.pem: "kubernetes-cluster1-secrets/istiod-service/certs"
vault.hashicorp.com/agent-inject-template-ca-key.pem: |
{{- with secret "kubernetes-cluster1-secrets/istiod-service/certs" -}}
{{ .Data.ca_key }}
{{ end -}}
vault.hashicorp.com/agent-inject-secret-ca-cert.pem: "kubernetes-cluster1-secrets/istiod-service/certs"
vault.hashicorp.com/agent-inject-template-ca-cert.pem: |
{{- with secret "kubernetes-cluster1-secrets/istiod-service/certs" -}}
{{ .Data.ca_cert }}
{{ end -}}
vault.hashicorp.com/agent-inject-secret-root-cert.pem: "kubernetes-cluster1-secrets/istiod-service/certs"
vault.hashicorp.com/agent-inject-template-root-cert.pem: |
{{- with secret "kubernetes-cluster1-secrets/istiod-service/certs" -}}
{{ .Data.root_cert }}
{{ end -}}
vault.hashicorp.com/agent-inject-secret-cert-chain.pem: "kubernetes-cluster1-secrets/istiod-service/certs"
vault.hashicorp.com/agent-inject-template-cert-chain.pem: |
{{- with secret "kubernetes-cluster1-secrets/istiod-service/certs" -}}
{{ .Data.cert_chain }}
{{ end -}}
vault.hashicorp.com/role: "istiod"
vault.hashicorp.com/auth-path: "auth/kubernetes-cluster1"
When we look at the vault-agent-init container traces, we should see something like this. Our control plane has correctly picked up the Vault injected secrets.
kubectl --kubeconfig kubecfg1.yml logs -n istio-system -l app=istiod -c vault-agent-init --tail=-1
==> Vault agent started! Log data will stream in below:
==> Vault agent configuration:
Cgo: disabled
Log Level: info
Version: Vault v1.12.0, built 2022-10-10T18:14:33Z
Version Sha: 558abfa75702b5dab4c98e86b802fb9aef43b0eb
2022-11-18T11:01:21.398Z [INFO] sink.file: creating file sink
2022-11-18T11:01:21.398Z [INFO] sink.file: file sink configured: path=/home/vault/.vault-token mode=-rw-r-----
2022-11-18T11:01:21.398Z [INFO] template.server: starting template server
2022-11-18T11:01:21.398Z [INFO] sink.server: starting sink server
2022-11-18T11:01:21.398Z [INFO] auth.handler: starting auth handler
2022-11-18T11:01:21.398Z [INFO] auth.handler: authenticating
2022-11-18T11:01:21.398Z [INFO] (runner) creating new runner (dry: false, once: false)
2022-11-18T11:01:21.398Z [INFO] (runner) creating watcher
2022-11-18T11:01:21.402Z [INFO] auth.handler: authentication successful, sending token to sinks
2022-11-18T11:01:21.402Z [INFO] auth.handler: starting renewal process
2022-11-18T11:01:21.402Z [INFO] sink.file: token written: path=/home/vault/.vault-token
2022-11-18T11:01:21.402Z [INFO] sink.server: sink server stopped
2022-11-18T11:01:21.402Z [INFO] sinks finished, exiting
2022-11-18T11:01:21.402Z [INFO] template.server: template server received new token
2022-11-18T11:01:21.402Z [INFO] (runner) stopping
2022-11-18T11:01:21.402Z [INFO] (runner) creating new runner (dry: false, once: false)
2022-11-18T11:01:21.402Z [INFO] (runner) creating watcher
2022-11-18T11:01:21.402Z [INFO] (runner) starting
2022-11-18T11:01:21.403Z [INFO] auth.handler: renewed auth token
2022-11-18T11:01:21.515Z [INFO] (runner) rendered "(dynamic)" => "/vault/secrets/root-cert.pem"
2022-11-18T11:01:21.515Z [INFO] (runner) rendered "(dynamic)" => "/vault/secrets/ca-cert.pem"
2022-11-18T11:01:21.515Z [INFO] (runner) rendered "(dynamic)" => "/vault/secrets/cert-chain.pem"
2022-11-18T11:01:21.516Z [INFO] (runner) rendered "(dynamic)" => "/vault/secrets/ca-key.pem"
2022-11-18T11:01:21.516Z [INFO] (runner) stopping
2022-11-18T11:01:21.516Z [INFO] template.server: template server stopped
2022-11-18T11:01:21.516Z [INFO] (runner) received finish
2022-11-18T11:01:21.516Z [INFO] auth.handler: shutdown triggered, stopping lifetime watcher
2022-11-18T11:01:21.516Z [INFO] auth.handler: auth handler stopped
When we look at the discovery container traces, we should see something like this:
kubectl --kubeconfig kubecfg1.yml logs -n istio-system -l app=istiod -c discovery --tail=-1
info Using istiod file format for signing ca files
info Use plugged-in cert at /vault/secrets/ca-key.pem
info x509 cert - Issuer: "CN=Intermediate CA,O=Istio,L=istiod-cluster1", Subject: "", SN: 39f67569f10d36a1fc91e9d82156b07d, NotBefore: "2022-11-18T11:11:59Z", NotAfter: "2032-11-15T11:13:59Z"
info x509 cert - Issuer: "CN=Root CA,O=Istio", Subject: "CN=Intermediate CA,O=Istio,L=istiod-cluster1", SN: dedf298a147681d6, NotBefore: "2022-11-17T22:01:54Z", NotAfter: "2024-11-16T22:01:54Z"
info x509 cert - Issuer: "CN=Root CA,O=Istio", Subject: "CN=Root CA,O=Istio", SN: f5bcd7e89bdb6248, NotBefore: "2022-11-17T22:01:52Z", NotAfter: "2032-11-14T22:01:52Z"
info Istiod certificates are reloaded
info spiffe Added 1 certs to trust domain cluster.local in peer cert verifier
We can see that our Istio control plane has correctly picked up our Vault injected certificates and private key. Mission accomplished!
Conclusion
In this article, we have successfully bootstrapped the Istio control plane with external Vault stored certificates and private keys. The steps to achieve this included:
- Storing the certificates and private key in per-cluster dedicated Vault secret mount paths
- Setting up Kubernetes Vault auth backends per cluster, linked to the proper ServiceAccount
- Defining a proper role and policy to allow access from the istiod ServiceAccount to the Vault secrets
- Adjusting Istio Pilot bootstrap parameters to:
- Inject the vault-agent-init sidecars
- Fetch the correct vault secrets containing our certificates and private key
- Use the right role and auth backend to do so
- Pick up the certificates and private key from the correct vault secret mount path
We can use exactly the same technique to inject ingress-gateway and egress-gateway certificates. When creating Istio Gateway objects, make sure to point serverCertificate, privateKey and caCertificates to the correct files within the /vault/secrets
mounted volume. We’ll leave this as an exercise for the reader.
By tying our certificate injection to Kubernetes ServiceAccount, we have now delegated certificate lifecycle management to an external secret Vault instance. External processes, like a service portal or a CI/CD pipeline, can now be created with dedicated roles and write/update policies, to provide the necessary certificate lifecycle management security.
###
If you’re new to service mesh and Kubernetes security, we have a bunch of free online courses available at Tetrate Academy that will quickly get you up to speed with Istio and Envoy.If you’re looking for a fast way to get to production with Istio, check out Tetrate Istio Distribution (TID). TID is Tetrate’s hardened, fully upstream Istio distribution, with FIPS-verified builds and support available. It’s a great way to get started with Istio knowing you have a trusted distribution to begin with, have an expert team supporting you, and also have the option to get to FIPS compliance quickly if you need to.Once you have Istio up and running, you will probably need simpler ways to manage and secure your services beyond what’s available in Istio, that’s where Tetrate Service Bridge comes in. You can learn more about how Tetrate Service Bridge makes service mesh more secure, manageable, and resilient here, or contact us for a quick demo.
###
If you’re new to service mesh, Tetrate has a bunch of free online courses available at Tetrate Academy that will quickly get you up to speed with Istio and Envoy.
Are you using Kubernetes? Tetrate Enterprise Gateway for Envoy (TEG) is the easiest way to get started with Envoy Gateway for production use cases. Get the power of Envoy Proxy in an easy-to-consume package managed by the Kubernetes Gateway API. Learn more ›
Getting started with Istio? If you’re looking for the surest way to get to production with Istio, check out Tetrate Istio Subscription. Tetrate Istio Subscription has everything you need to run Istio and Envoy in highly regulated and mission-critical production environments. It includes Tetrate Istio Distro, a 100% upstream distribution of Istio and Envoy that is FIPS-verified and FedRAMP ready. For teams requiring open source Istio and Envoy without proprietary vendor dependencies, Tetrate offers the ONLY 100% upstream Istio enterprise support offering.
Need global visibility for Istio? TIS+ is a hosted Day 2 operations solution for Istio designed to simplify and enhance the workflows of platform and support teams. Key features include: a global service dashboard, multi-cluster visibility, service topology visualization, and workspace-based access control.
Get a Demo
